Fluke 8062A - Page 22

8062A
Instruction Manual
1-10
Table 1-2. 8062A Specifications (cont)
General
Maximum Common Mode
Voltage............................... 500V dc or ac rms
Display Update Rate......... 2.5 readings/second
Display............................... 4½ digit duplex LCD (19,999 count), leading
zero suppression, autopolarity.
Electromagnetic
Compatibility.....................
In an RF field of 1 V/m on all ranges and
functions: Total Accuracy = Specified
Accuracy + 2.3% of range. Performance
above 1 V/m is not specified.
Display Annunciators....... BT (low battery indicator), REL: (relative
function enabled).
AND R (continuity
function enabled), and — (bar indicates
continuity detected)."""
A/D Converter.................... Dual-slope converter
Power ................................. Single standard 9V battery (NEDA 1604), or
Fluke A-81 Battery Eliminator option
available for 100, 115, or 230V ac operation.
Battery Life ........................ Typically 170 hours with an alkaline battery.
BT appears on display when approximately
20% of battery life remains.
Size..................................... 180 mm L x 86 mm W x 45 mm H (7.1” L x
3.4” W x 1.8” H)
Weight................................ .41 kg (14.5 oz.)
Shock and Vibration ......... MIL-T-28800B
Environmental
Operating Temperature .... 0 to 50°C
Storage Temperature........ -35 to + 60°C
Accuracy Temperature
Coefficient .........................
0.1 x the applicable accuracy specification
per °C (plus the initial 23°C specification) for
0 to 18°C and 28 to 50°C.
Relative Humidity.............. 0 to 80% R.H. from 0 + 35°C, 0 to 70%
from + 35°C to + 50°C except 0 to 70% R.H.
for MΩ range above 20 MΩ.
Safety
Safety Standards............... Designed to Protection Class II
requirements of IEC 348, UL1244 ANSI
C39.5, and CSA Bulletin 556B.
Certifications..........................
