Fluke DSP-4300 User Manual

DSP-4000 Series
Users Manual
3-34
Test Summary: PASS
Cable ID: ROOM123, PORT B
Headroom: 7.3 dB (NEXT 12-36)
Site: ABC BANK
Date / Time: 08/09/2000 09:06:17am
Operator: JOHN DOE Test Standard: TIA Cat 6 Basic Link
Standards Version: 4.06 Software Version: 4.06 Cable Type: UTP 100 Ohm Cat 6
NVP: 69.0% Fault Anomaly Threshold: 15% FLUKE DSP-4100 S/N: 1234567 LIA081
Shield Test: N/A FLUKE DSP-4100SR S/N: 0000001 LIA081
Wire Map
PASS
1
|
1
2
|
2
3
|
3
4
|
4
5
|
5
6
|
6
7
|
7
8
|
8
S
Length (ft), Limit 308 [Pair 12] 111
Prop. Delay (ns), Limit 518 [Pair 12] 163
Delay Skew (ns), Limit 45 [Pair 12] 7
Resistance (ohms)
Impedance (ohms), Limit 80-120 [Pair 12] 114
Anomaly (ft)
Attenuation (dB) [Pair 36] 12.6
Frequency (MHz) 250.0
Limit (dB) 31.8
-50
-25
0
25
50
0 407
HDTDR%
(ft)
0
10
20
30
40
50
60
1 350
AttenuationdB
Frequency (MHz)
Worst Margin Worst Value
PASS MAIN MAINSR SR
Worst Pair 12-36 36-45 12-36 36-45
NEXT (dB) 63.4 43.2 43.8 43.2
Freq. (MHz) 13.0 242.0 222.5 242.0
Limit (dB) 56.1 35.5 36.1 35.5
Worst Pair 36 45 36 45
PSNEXT (dB) 40.7 41.7 40.7 41.7
Freq. (MHz) 223.0 242.0 223.0 242.0
Limit (dB) 33.6 33.0 33.6 33.0
0
20
40
60
80
100
1 350
NEXTdB
Frequency (MHz)
0
20
40
60
80
100
1 350
NEXT @ RemotedB
Frequency (MHz)
PASS MAIN MAINSR SR
Worst Pair 78-36 12-45 36-45 36-45
ELFEXT (dB) 28.0 30.6 27.6 27.2
Freq. (MHz) 184.0 144.5 227.5 227.5
Limit (dB) 19.9 22.0 18.0 18.0
Worst Pair 36 36 36 36
PSELFEXT (dB) 25.8 26.0 25.4 25.4
Freq. (MHz) 184.5 185.5 247.0 232.5
Limit (dB) 16.9 16.8 14.3 14.8
0
20
40
60
80
100
1 350
ELFEXTdB
Frequency (MHz)
0
20
40
60
80
100
1 350
ELFEXT @ RemotedB
Frequency (MHz)
PASS MAIN MAINSR SR
Worst Pair 12-36 12-45 12-36 36-45
ACR (dB) 60.7 67.0 31.5 31.2
Freq. (MHz) 12.9 8.9 240.0 242.0
Limit (dB) 49.5 53.2 4.5 4.3
Worst Pair 12 12 36 36
PSACR (dB) 59.3 61.4 28.8 29.3
Freq. (MHz) 12.9 12.3 223.0 242.0
Limit (dB) 47.2 47.7 3.7 1.7
0
20
40
60
80
100
1 350
ACRdB
Frequency (MHz)
0
20
40
60
80
100
1 350
ACR @ RemotedB
Frequency (MHz)
PASS MAIN MAINSR SR
Worst Pair 12 45 45 78
RL (dB) 21.0 20.8 18.5 17.3
Freq. (MHz) 13.2 16.6 249.0 250.0
Limit (dB) 19.0 19.0 11.3 11.3
0
10
20
30
40
50
60
1 350
RLdB
Frequency (MHz)
0
10
20
30
40
50
60
1 350
RL @ RemotedB
Frequency (MHz)
Compliant Network Standards:
10BASE-T 100BASE-TX 100BASE-T4
1000BASE-T ATM-25 ATM-51
ATM-155 100VG-AnyLan TR-4
TR-16 Active TR-16 Passive
oy81f.wmf
Figure 3-13. Autotest Report in Graphical Format
