DSP-4000 Series
Users Manual
2-44
Battery Status
The test tool displays a message when its battery voltage or the remote battery
voltage is low. Table 2-7 shows the battery status messages and what you should
do if a battery message appears.
When you turn on the remote, the LEDs briefly indicate the battery charge level.
All five LEDs light up if the battery is fully charged; fewer indicate partial charge.
DSP-4300 test tools show the battery status on the Autotest display. If the main
unit is connected to a remote, the test tool also shows the approximate number of
Autotests you can run with the currently-selected test standard. This number is
based on the battery with the lower charge level.
Note
To ensure continued operation while charging the battery, always
connect the ac adapter/charger when the message WARNING
RECHARGEABLE BATTERY VOLTAGE IS LOW appears.
Table 2-7. Battery Status Messages
Message Displayed What You Should Do
WARNING RECHARGEABLE BATTERY
VOLTAGE IS LOW.
Connect the ac adapter/charger.
RECHARGEABLE BATTERY VOLTAGE
IS TOO LOW TO OPERATE.
Turn the test tool off and connect the ac
adapter/charger. If the tool does not operate
when you turn it on, turn it off again and allow
the battery to charge for about 30 minutes.
WARNING REMOTE BATTERY VOLTAGE
IS LOW.
Connect the ac adapter/charger to the remote.
WARNING REMOTE BATTERY
VOLTAGE IS TOO LOW TO OPERATE.
Connect the ac adapter/charger to the remote.
You might need to charge the battery for a short
time before the remote will operate.
INTERNAL DATA STORAGE BATTERY
VOLTAGE IS LOW.
Have the lithium battery replaced at a Fluke
Networks Service Center.
