Page #107 background imageLoading...
Page #107 background image
Running Individual Tests
The HDTDX Analyzer
4
4-7
If the test tool does not detect a remote, the following message appears: NO
REMOTE DETECTED.
HDTDX Analyzer Results
When the HDTDX analyzer test is complete, the HDTDX analyzer results screen
appears. Table 4-2 describes the items on the analyzer screen.
Table 4-2. Items on the HDTDX Analyzer Results Screen
Item Description
Pairs
The cable pairs relevant to the results.
Peak
The highest magnitude of crosstalk measured on the cable pair. A peak
over 50 indicates a crosstalk level that exceeds the limit specified by the
selected test standard. Crosstalk levels are adjusted to compensate for
cable attenuation.
Distance
The measured distance from the main unit to the peak crosstalk value.
@ View Plot
Press to see a plot that shows where crosstalk is detected on the cable.
