DSP-4000 Series
Users Manual
2-4
Quick Start
This section is for users who want to start using the test tool immediately with
minimal instruction. For suggestions on additional reading that may be helpful to
you, see Using this Manual in Chapter 1. To get started with the optional Fiber
Test Adapters, refer to the Fiber Test Adapter users manual.
Note
New features may be available with software upgrades. Visit the
Fluke Networks website at www.flukenetworks.com or contact your
Fluke Networks representative for information on upgrades.
Powering the Test Tool
Before powering the test tool or remote with the NiMH battery pack, charge the
battery for about 3 hours. To charge the battery, connect the ac adapter/charger to
the test tool or remote and to ac line power. You can operate the unit on ac power
while the battery charges. A fully-charged battery typically lasts at least 8 hours.
See Battery Status later in this chapter for information on battery status
messages.
Note
The ac adapter/charger will not power the test tool when the battery
pack is removed.
Using the Menus
The test tools setup configuration, test selections, and test results are presented in
a menu system. Table 2-2 shows the keys used to select items and move between
screens in the menu system.
Table 2-2. Key Functions for the Menu System
Key Function
U D L R Allow up, down, left, and right movement on the display.
E Selects the highlighted item.
T Starts the highlighted test.
e Exits the current screen.
!@
#$
Softkeys select the function displayed on the screen area above the key.
Softkey functions depend on the screen displayed.
