Running Individual Tests
Single Tests for Coaxial Cabling
4
4-17
BNC “T”
Connector
12345678
PC
12345678
PC
12345678
PC
For Length Test,
remove far-end
Terminator
Channel LIA
Test Tool
OFF
PRINT
MONITOR
SETUP
SPECIAL
FUNCTIONS
SINGLE
TEST
AUTO
TEST
DSP-4000
CABLE ANALYZER
TALK
EXIT
ENTER
TEST
SAVE
1
23
4
FAULT
INFO
oy22f.eps
Figure 4-4. Single Test Connections for Coaxial Cabling
