Flux Beambox User Manual

62
7.6.1 First Reflecting Mirror
Goal: Make the 2 dots shot from
the top-left and the bottom-left
corner overlap.
Directions:
󱦯
Go to Touch Panel > Maintenance and wait for
the laser head to go back to home position. Then
press "Release Motors".
󱦱
Put a piece of double-sided tape over the
second reflecting mirror.
󱦳
Move the laser head to the top-left corner
manually. Close the door and press "Laser Pulse".

Flux Beambox Specifications

General

Laser Power	40W
Weight	22 kg (48.5 lbs)
Laser Type	CO2
Camera	Yes
Connectivity	Wi-Fi
Supported File Types	SVG, DXF, JPG, PNG
Power Supply	110V/220V
