Data Logger | 111
Model FT3
Data Logger
Model FT3
Displaying Data Log Records
The data logger supports 31 records, record #1 being the latest recorded value and 31 being the
oldest.
From the normal operating mode, press F1 and F4 keys at the same time:
F1 F2 F3 F4
NOTE! Record #1 is the most recent interval total, record #31 is the oldest.
This display screen will appear for only 1 second and will then show:
F1 F2 F3 F4
The Date and Time is displayed on line 1 and the interval total on line 2. The interval total is based on
the ow units selected in the meter (total mass ow or total volumetric ow).
Pressing F2 will display the next record, F1 will display the previous record.
Press F4 to exit to the normal mode at any time.
Data Log Rec #1
10/07/13 15:54
ITOT= 152345.3
