Fox Thermal FT3 - Hart

Scope - HART Communications
The Fox Thermal model FT3 transmitter complies with HART Protocol Revision 7.1. A HART-enabled
FT3 includes "BH" in the model number. This section of the manual species all the device-specic
features and documents HART Protocol implementation details (e.g., the Engineering Unit Codes
supported). The functionality of this Field Device is described suciently to allow its proper
application in a process and its complete support in HART-capable Host Applications.
Purpose
This specication provides a complete description of this Field Device from a HART Communication
perspective. The specication is designed to be a technical reference for HART capable Host
Application Developers, System Integrators and knowledgeable End Users. It also provides
functional specications (e.g., commands and performance requirements) used during development,
maintenance and testing. This document assumes the reader is familiar with HART Protocol
requirements and terminology.
References
HART Smart Communications Protocol Specication. HCF_SPEC-12.
Device Identication
Product Overview
The FT3 HART communication option can be monitored and congured using a HART master device
or a hand-held communicator.
Communications | 101
Model FT3
Communications
Manufacturer Name: Fox Thermal Instruments Model Name: FT3
Manufacture ID Code: 24635 (603b hex) Device Type Code: 57583 (E0EF Hex)
HART Protocol Revision: 7.1 Device Revision: 1
No. of Device Variables: None
Physical Layers
Supported:
FSK
Physical Device
Category:
Transmitter, DC-isolated Bus
Device
