Fox Thermal FT3 - Modbus Communication Protocol and Parameters

Modbus Parameters
To program the communication parameters, start at the SET PARAMETERS menu:
F1 F2 F3 F4
Then press I/O (F1) to set Inputs/Outputs:
F1 F2 F3 F4
Then press COM (F1) to select communication parameters.
Set Bus protocol for Modbus:
F1 F2 F3 F4
Press NXT (F1) repeatedly until Modbus is selected as shown and then press OK (F4) to accept the
setting.
The following communication settings apply only to Modbus:
F1 F2 F3 F4
Press NXT (F1) repeatedly until the correct selection is shown then press OK (F4) to accept the
setting.
Selections are: 115200 9600
76800 4800
57600 2400
38400 1200
19200
SET PARAMETERS
I/O FLO DSP EXIT
SET I/O
COM I/O 420 EXIT
Comm=Modbus
NXT OK
Baud=9600
NXT OK
Communications | 99
Model FT3
Communications
