+2°
-2°
FLOW
FLOW
+2°
-2°
FLOW
FLOW
Unequal Length Sensor Elements
Install the shorter sensor element upstream from the longer one.
Fig. 2.7: Unequal Length Sensor Elements
Equal Length Sensor Elements
Install ow meter with both sensor elements facing the ow stream within ±2˚.
Fig. 2.8: Equal Length Sensor Elements
Installation | 26
Model FT3
Installation
