15 SPECIFICATIONS
PEDAL INTERFACE
Connectors: (2) 1/4" TRS phone jack
Format: Pedal: 10–100 kΩ max
Tip-Ring Switch: make/break; momentary or latching
Sleeve-Ring Switch: make/break; momentary or latching
FASLINK II INTERFACE
Connectors: (1) XLR-F
WARNING: Connect ONLY to the FASLINK II connector on a Fractal Audio FC Series controller
GENERAL
Finish: Powder-coated steel chassis
Controls: 12 buttons, 8 knobs (5 with additional “push” functions)
Display: 800×480 high contrast color LCD
Dimensions: 11.1” W. × 4.05” H. × 9.3” D.
281mm W. × 103mm H. × 236mm D.
Weight: 7 lbs 1.6 oz (3.22 kg)
Input Voltage: 90–264 VAC, 47 – 63 Hz (universal input)
Power Consumption: <40 W
Backup Battery Life: >10 years
Backup Battery Type: CR-2032
Ventilation: Onboard fan with side and bottom venting. WARNING: Do not block vent holes!
ENVIRONMENTAL
Operating Temperature: 32 to 122 °F (0 to 50 °C)
Storage Temperature: -22 to 167 °F (-30 to 70 °C)
Humidity: Max. 90% non-condensing
