5 PRESETS
THE RULES OF FM3 CABLES
No cable = No sound. Even one missing link will break the chain.
Signal flows from LEFT to RIGHT.
A cable MUST originate from a BLOCK or a SHUNT. You cannot start from an EMPTY location.
If you try to connect to an EMPTY location, a SHUNT will be created there.
You can ONLY connect to blocks in the next column to the right.
The diagram below illustrates the above:
You may freely SPLIT or MERGE up to four ways at any point. This is sonically transparent and there is zero
risk of signal degradation or phase problems. CROSSING is also possible. Here are some examples:
The
is the block where we will begin.
The
shows valid possible destinations.
The
symbol shows destinations that are illegal/unavailable.
Any columns farther left or right would also be illegal/unavailable.
If the
were in a different ROW, every would still be in the same place.
Split Merge Cross Complex
