10 LAYOUTS & SWITCHES
Layout 1: Presets is designed for switching presets. It shows
three presets at once, with press and hold functions for BANK
UP and BANK DOWN on the left and right switches.
Hold the middle switch for the Master Layout Menu (MLM).
Layout 2: Scenes shows scenes 1, 2, 3, with hold functions
on the left and right switches to change the “View” to show
scenes 4, 5, 6 or 7, 8, and Tuner.
Hold the middle switch for the Master Layout Menu.
Layout 4: Channels is used to change the channel on
designated blocks. The default is AMP 1 (A, B, C) with hold
functions on the left and right switches changing the View to
reveal other effects as shown.
Hold the middle switch for the Master Layout Menu.
Layout 6: Per-Preset shows the rst three per-preset switches
(“placeholders”) with hold functions on the left and right
switches changing the View to reveal a total of 12 per-preset
switches. You will need to add per-preset switch denitions
(see p. 79) for this layout to work. The rst few factory
presets include some of these as examples.
Hold the middle switch for the Master Layout Menu.
Layout 3: Effects is used to engage or bypass effects. The
defaults are Drive 1, Delay 1, Reverb 1, with hold functions on
the left and right switches changing the View to reveal other
effects as shown.
Hold the middle switch for the Master Layout Menu.
Layout 5: Looper offers essential Looper controls.
Hold the middle switch for the Master Layout Menu.
Layout 7 is an example to accompany a short tutorial. It
represents one possible idea for a simple FM3 performance
layout. There is no switch in this layout to return to the MLM,
though you can easily add one yourself or use the front panel
“E” knob.
Layout 8 contains utilities: Tap Tempo and Tuner.
TAP:P1 TAP:P2 TAP:P3
1: PRESETS
HOLD: Bank-1
HOLD: MLM
HOLD:
Bank+1
TAP:S1
TAP:S2
TAP:S3
Three Views cycle through the remaining scenes: [4,5,6] then [7,8]
The unused switch contains a TUNER.
2:SCENES
HOLD: MLM
HOLD:
View -1 HOLD: View +1
TAP:AMP 1A TAP:AMP 1B TAP:AMP 1C
The Views cycle through channel switches for four different effects:
Amp 1, Drive 1, Drive 2, Delay 1
4:CHANNELS
HOLD: MLM
HOLD:
View -1 HOLD: View +1
TAP:Record TAP:Play/Stop TAP:Undo
A second View contains tap functions: ONCE, REVERSE, and HALF SPEED.
5:LOOPER
HOLD: MLM
HOLD:
View -1 HOLD: View +1
TAP:PP1Tap TAP:PP2Tap TAP:PP3Tap
Four Views cycle through 12 total Per-Preset Tap “Placeholder” functions.
Per-Preset Hold functions are not supported in this layout.
6:PER PRESET
HOLD: MLM
HOLD:
View -1 HOLD: View +1
TAP:Drive 1 TAP: Delay 1 TAP: Reverb 1
Four Views cycle through three effects each:
[Chorus 1, Flanger 1, Rotary 1] [Pitch 1, MultiDly 1, Plex 1] [Comp1, Phaser 1, TremPan1]
3:EFFECTS
HOLD: MLM
HOLD:
View -1 HOLD: View +1
TAP TAP TAP
7:PERFORM
HOLDHOLD
HOLD
8:UTILITIES
TAP: Tempo TAP:-- TAP: Tuner
HOLD: MLMHOLD: --
HOLD: --
FM3 FACTORY LAYOUTS
