Install thethree-person rear bench seat on
thirdrow of seats 3.
#
Install thefour-person rear bench seat on
fourth row of seats 4.
Vehicles withthree rowsofseats
1
First rowofseats
2
Second row of seats
3
Thirdrow of seats: four-person rear bench
seat withstrut
#
Install thefour-person rear bench seat on
thirdrow of seats 3.
Removing the rear bench seat
Performthese taskscarefully withthe assistance
of asecond person.
#
To remove thecovers of themounting
shells: push clip 1 in thedirection of the
arrow and detach cover 2 by pushing to the
toprear at an angle.
#
Push release handle 2 forthe benchseat all
theway down and hold it therewhile tilting
thebenchseat backwards slightlyatthe
same time using therelease handle and pull it
slightly backwards.
#
Letgoofthe release handle.
The locks on thebenchseat legs will be
unlockedand redindicator tabs 3 on the
housing of release handle 2 will be visible.
#
Hold theunlockedbenchseat by grab han‐
dles 1 and pull backwards slightly.
#
Tilt benchseat 1 backwards and pull it out
of themounting shells.
%
If thebenchseat cannot be pulled out of the
mounting shells, thebenchseat maybe
wedged in theseat anchorage. This can hap‐
pen if thebenchseat is tilted toofar back‐
wards.
If thebenchseat cannot be pulled out of the
mounting shells, youcan rectify this situation as
follows:
