Thermistor Resistance Values
18 7.051 2.09859271 69 1.213 4.039284017
19 6.778 2.14682606 70 1.177 4.062450215
20 6.516 2.19524793 71 1.142 4.085229093
21 6.267 2.24333597 72 1.109 4.106941536
22 6.028 2.29151689 73 1.076 4.12888601
23 5.8 2.33944954 74 1.045 4.149715216
24 5.581 2.38741691 75 1.015 4.17007359
25 5.372 2.43506494 76 0.986 4.189944134
26 5.172 2.48247664 77 0.957 4.210004953
27 4.981 2.52951096 78 0.93 4.228855721
28 4.797 2.57653834 79 0.904 4.247168554
29 4.622 2.62291710 80 0.878 4.265640683
30 4.453 2.66931854
Note: the AD value in the table is calculated on the basis of the pull-down resistor is 5.1K.
2. THE PARAMETER OF OUTDOOR COMPRESSOR TEMPERATURE SENSOR：
R(0)=187.25k B(0100)=3979)
Temperature
(℃)
Resistance(k) Voltage(V)
Temperature
(℃)
Resistance
(k)
Voltage(V)
-20 542.867 0.06185563 51 19.907 1.273074475
-19 512.839 0.06543004 52 19.148 1.310312934
-18 484.672 0.06917993 53 18.422 1.348029498
-17 458.239 0.07311215 54 17.728 1.386170907
-16 433.423 0.07723358 55 17.065 1.424680494
-15 410.115 0.08155140 56 16.43 1.463624623
-14 388.213 0.08607312 57 15.822 1.502961719
-13 367.625 0.09080590 58 15.241 1.542579738
-12 348.264 0.09575738 59 14.684 1.582573078
-11 330.048 0.10093573 60 14.151 1.622834232
-10 312.904 0.10634837 61 13.64 1.663405088
-9 296.761 0.11200385 62 13.151 1.704175229
-8 281.556 0.11790981 63 12.682 1.745200698
-7 267.227 0.12407536 64 12.233 1.78637104
-6 253.72 0.13050821 65 11.802 1.827760456
-5 240.982 0.13721739 66 11.388 1.869364416
-4 228.965 0.14421140 67 10.992 1.910971223
-3 217.624 0.15149895 68 10.611 1.952788467
-2 206.917 0.15908889 69 10.246 1.994602839
-1 196.805 0.16699001 70 9.896 2.036415908
0 187.25 0.17521257 71 9.559 2.078366648
1 177.957 0.18402550 72 9.236 2.120229484
2 169.186 0.19319719 73 8.925 2.162162162
3 160.903 0.20273937 74 8.627 2.203928178
4 153.179 0.21252789 75 8.341 2.245558418
5 145.685 0.22297275 76 8.065 2.287251934
