INSTALLATION OF THE OUTDOOR UNIT
Startup And Operation
Present the owner or operator of the equipment with the Installation &
Operation Manual, all accessory installation instructions, and the name,
address, and telephone number of the Authorized Friedrich Warranty
Service Company in the area for future reference if necessary. Inspect
the unit for any damage to the coils and tubing that could cause a
leak.
NOTICE
This unit is certied to operate in cooling mode under these
maximum conditions. Any operation beyond these conditions may
result in intermittent operation.
Indoor temperature: 90 °F (45% relative humidity)
Outdoor temperature: 110 °F (25% relative humidity)
If unit is heat pump equipped, it is certied to operate in heating
mode under these maximum conditions. Any operation beyond
these conditions may result in intermittent operation.
Indoor temperature: 80 °F (humidity does not affect operation)
Outdoor temperature: 75 °F (60% relative humidity)
Test Operation
System Checks
1. Conceal refrigerant pipes where possible.
2. Make sure drain hose slopes downward along entire length at
a slope of 1/4”(inch) per ‘(foot).
3. Ensure all refrigerant pipes and connections are properly
insulated.
4. Fasten pipes to outside wall, when possible.
5. Seal and weatherproof wall hole which the interconnecting
wires and refrigerant pipes pass through.
Perform test operation after completing gas leak and electrical
safety check.
1. Turn on electrical disconnect to outdoor unit.
2. Push the “ON/OFF” button on Remote Controller to begin
testing, or if remote is not available press auto start switch on
indoor unit.
3. Push MODE button, select COOLING, HEATING, FAN mode to
conrm all functions.
Indoor Unit
1. Do all Remote controller’s buttons function properly?
2. Do the display panel lights work properly?
3. Does the swing louver function properly?
4. Does the drain work?
Outdoor Unit
1. Push the mode button to COOL and adjust the room
setting to 61 °F. Wait up to 3 minutes for compressor time delay.
Does compressor and outdoor fan turn on in cooling mode?
2. Push the mode button to HEAT and adjust the room
setting to 85 °F( Wait up to 3 minutes for compressor time delay.
Does compressor and outdoor fan turn on in heat mode?
Unit protection will prevent the unit from restarting for 3 minutes if
operations stops, or modes are changed.
Preheat
At the beginning of the HEATING operation, the airflow from the indoor
unit is discharged 2-5 minutes later.
Defrost
In HEATING operation the appliance will defrost (de-ice)
automatically to raise efficiency. This procedure usually
lasts 2-10 minutes. During defrosting, fans stop operation.
After defrosting completes, it returns to HEATING mode
automatically.
No. Items to be checked Possible malfunction
1
Has the unit been
installed correctly?
2
The unit may drop, shake or
emit noise.
Have you done the
refrigerant leakage test?
3
It may cause insufficient cooling
(heating) capacity.
Is heat insulation of
pipeline sufficient?
4
It may cause condensation and
water dripping.
Is water drained well?
5
It may cause condensation and
water dripping.
6
It may cause malfunction or
damage the parts.
Is the voltage of power
supply according to the
voltage marked on the
nameplate?
7
Is electric wiring and
pipeline installed
correctly?
It may cause malfunction or
damage the parts.
It may cause electric leakage.
Is the unit grounded
securely?
8
Does the power cord
follow the specification?
9
It may cause malfunction or
damage the parts.
Is there any obstruction
in air inlet and air outlet?
10
It may cause insufficient cooling
(heating).
11
It may cause malfunction or
damaging the parts.
Are the dust and
debris caused
during installation
removed?
The gas valve and liquid
valve of connection pipe
are open completely?
It may cause insufficient cooling
(heating) capacity.
