Friedrich FPHW093B - Temperature Sensor; Thermistor Resistance Values

99 PB
APPENDIX
Thermistor Resistance Values
38
5-3. Temperature Sensor
Parameter table attached:
1. THE PARAMETER OF THE INDOOR COIL AND INDOOR ROOM SENSOR ,THE PARAMETER OF
THE OUTDOOR COIL AND OUTDOOR AMBIENT TEMP SENSOR:
（R(0)=15k B(0/100)=3450）
Temperature(℃)
Resistance(k) Voltage(V)
Temperature(℃)
Resistance(k) Voltage(V)
-20 38.757 0.58143512 31 4.292 2.715076661
-19 36.844 0.60795346 32 4.137 2.76063657
-18 35.038 0.63530819 33 3.989 2.805589174
-17 33.331 0.66352684 34 3.847 2.850117358
-16 31.719 0.69257720 35 3.711 2.894109636
-15 30.196 0.72246147 36 3.58 2.937788018
-14 28.755 0.75321223 37 3.455 2.980713033
-13 27.392 0.78480857 38 3.335 3.023117961
-12 26.103 0.81722911 39 3.219 3.065272268
-11 24.882 0.85051031 40 3.108 3.106725146
-10 23.727 0.88458737 41 3.001 3.147759536
-9 22.632 0.91951536 42 2.899 3.187898487
-8 21.594 0.95527085 43 2.801 3.227439565
-7 20.611 0.99179340 44 2.706 3.266717909
-6 19.678 1.02913875 45 2.615 3.305249514
-5 18.794 1.06721353 46 2.528 3.342947037
-4 17.954 1.10609872 47 2.444 3.380169671
-3 17.158 1.14565549 48 2.363 3.416856492
-2 16.401 1.18599135 49 2.286 3.45247766
-1 15.683 1.22696435 50 2.211 3.487894953
0 15 1.26865672 51 2.139 3.522585993
1 14.351 1.31098658 52 2.07 3.556485356
2 13.734 1.35393437 53 2.003 3.590032381
3 13.148 1.39741342 54 1.939 3.622673675
4 12.589 1.44157386 55 1.877 3.654865988
5 12.058 1.48618720 56 1.818 3.686036427
6 11.553 1.53125563 57 1.76 3.717201166
7 11.071 1.57689691 58 1.705 3.747244673
8 10.613 1.62286005 59 1.652 3.776658768
9 10.176 1.66928515 60 1.6 3.805970149
10 9.76 1.71601615 61 1.551 3.834009923
11 9.363 1.76311968 62 1.503 3.861880963
12 8.985 1.81043663 63 1.457 3.888973616
13 8.624 1.85805887 64 1.413 3.91524643
14 8.279 1.90597205 65 1.37 3.941267388
15 7.951 1.95387327 66 1.328 3.967019291
16 7.637 2.00204130 67 1.289 3.991234935
17 7.337 2.05033368 68 1.25 4.015748031
