SPECIFICATIONS
Dimensions FPHSR09A3B, FPSHR12A3B
DIMENSIONAL DRAWINGS
OUTDOOR UNITS / FPHSR09A3B, FPSHR12A3B
12
Outdoor units:
Width Depth Height
Model
L1 L2 L3 L4 L5 L6 L7
(in.) (in.) (in.) (in.) (in.) (in.) (in.)
FPHSR09A3B
20 1/16 12 19/32 34 7/8 31 7/8 11 23 13
FPSHR12A3B
20 1/16 12 19/32 34 7/8 31 7/8 11 23 13
Figure 207 (9-12k Outdoor Unit Dimensions)
