SPECIFICATIONS
9-24k (230v)
Model No.
FAHFW09A3A
FPHSR09A3B
FAHFW12A3A
FPHSR12A3B
FAHFW18A3A
FPHSR18A3B
FAHFW24A3A
FPHSR24A3B
Rated Current
Cooling (A) 2.5 4.3 6.1 8.7
Heating (A) 3.1 4.1 6.5 9.3
MOP (Rating of Over-current Protective
Device
A 15.0 15.0 30.0 35.0
MCA (Minimum Circuit Ampacity) A 9.5 10.5 20.0 22.0
Power and Communication Cable 4 x 14AWG 4 x 14AWG 4 x 14AWG 4 x 14AWG
System
Compressor type
Rotary Rotary Rotary Rotary
Compressor MFG GMCC GMCC GMCC GMCC
Compressor model # TSN108D34UEZ3 TSN108D34UEZ3 TTN240D57UMT TTN240D57UMT
Expansion Device EEV EEV EEV EEV
Indoor DC motor Yes Yes Yes Yes
Outdoor DC motor Yes Yes Yes Yes
Evaporator material
Copper tube and
Aluminum Fin
Copper tube and Alu-
minum Fin
Copper tube and Alu-
minum Fin
Copper tube and Alu-
minum Fin
Condenser material
Copper tube and Alu-
minum Fin
Copper tube and Alu-
minum Fin
Copper tube and Alu-
minum Fin
Copper tube and Alu-
minum Fin
Connecting Pipe Diameter
Liquid Pipe inch 1/4 1/4 1/4 3/8
Gas Pipe inch 3/8 3/8 1/2 5/8
Max. Pipe Length (Total) ft 66 66 66 100
Max. Elevation (indoor units higher than
outdoor unit)
ft 50 50 50 50
Pre-charge Pipe Length ft 25 25 25 25
Additional refrigerant charge per foot
after 25 ft
oz. /foot 0.2 0.2 0.2 0.3
Others
Dimensions
Indoor Unit/ in
33 7/8x11 3/16x8 1/2 33 7/8x11 3/16x8 1/2
45 3/16x13 1/8x9 15/16 45 3/16x13 1/8x9 15/16
Outdoor Unit/
in
31 7/8x23x11 31 7/8x23x11
33 7/8x25 9/16x12
3/16
35 3/8x13 1/2x29 1/2
Net Weight
Indoor Unit(/
Ibs.)
22.1 22.1 34.2 34.2
Outdoor Unit(/
Ibs.)
70.6 70.6 97 112
Packing Dimensions
Indoor Unit/ in
36 9/16x15 x11 3/16 36 9/16x15 x11 3/16 47 13/16x15 3/16x13 47 13/16x15 3/16x13
Outdoor Unit/
in
37x25 3/16x15 3/16 37x25 3/16x15 3/16 39 3/16x28 3/4x17 1/2 41 3/4x17 3/4 x32 1/4
Gross Weight
Indoor Unit
(Ibs.)
26.5 26.5 37.4 37.4
Outdoor Unit
(Ibs.)
82 82 106 121.0
One Set Loading Capacity (20GP/40GP/40’HQ) 90/185/210 90/185/210 50/115/130 42/100/105
Outdoor Unit Loading Capacity (20GP/40GP/40’HQ) 108/222/296 108/222/296 93/189/189 54/110/165
Indoor Unit Loading Capacity (20GP/40GP/40’HQ) 310/623/698 310/623/698 173/368/406 173/368/406
Features Yes Yes Yes Yes
