Friendly Robotics robomower RL800 - Page 73

3
3.2.4 Edge Problems
18
If the problem appears in
Dock zone, please refer to
section 3.2.11.6 (pa
g
e 3.33)
3.2.4.1
Robomow does
not complete the
Edge
Refer to the error
message in the LCD
(See paragraph 3.1)
Y
ES
NO
Stops
displaying
an error
Does the
Robomow leave
the edge or stop
displayin
g
an error
message?
Adjust perimeter wire in
areas where bumper is
being activated
Confirm Robomow is
operated in the right
zone
Choose ‘Set default ed
g
e’
under ‘User preferences’
menu and retest
‘Learn edge’ is done per
zone – choosin
g
the wron
g
zone in the LCD will cause
the Robomower to perform
different edge distance.
Observe mower
on edge – is wire
properly placed to
prevent bumper
activation while in
ed
g
e?
Leaves the
edge and
starts to mow
Perform ‘Edge termination
test’ under the
‘Service>Tests’ menu – it
should point about the
reason which causes the
mower to leave the edge
before it completed.
A
ccess ‘Learn Ed
g
e’ in menu (under ‘User
Preferences>Zones setup’) and perform the
following:
 Place the mower several feet from the Edge
 Choose ‘Learn Edge’ (if the user has more
than one zone activated for operating time,
be sure to select ‘Learn edge’ in the zone
where the problem exists.
 Press ‘GO’ to initiate the operation (the
mower blades will not operate in this feature).
 At the completion of one full edge operation,
press the ‘Stop’ button.
 The process in now complete and edge
mowing will now operate completely.
