P1
Spec
P1
Spec
P1.1
VDD_5V
P1.2
DGND
P1.3
XvVD23
P1.4
XvVD22
P1.5
XvVD21
P1.6
XvVD20
P1.7
XvVD19
P1.8
XvVD18
P1.9
XvVD15
P1.10
XvVD14
P1.11
XvVD13
P1.12
XvVD12
P1.13
XvVD11
P1.14
XvVD10
P1.15
XvVD7
P1.16
XvVD6
P1.17
XvVD5
P1.18
XvVD4
P1.19
XvVD3
P1.20
XvVD2
P1.21
XvVDEN
P1.22
XEINT10
P1.23
XvVSYNC
P1.24
XvHSYNC
P1.25
XvVCLK
P1.26
XpwmTOUT1
P1.27
XuoVBUS
P1.28
XuoDRVVBUS
P1.29
XuoID
P1.30
XEINT8
P1.31
XuoDM
P1.32
XuhDM
P1.33
XuoDP
P1.34
XuhDP
P1.35
XadcAIN9_XP
P1.36
XadcAIN8_XM
P1.37
XadcAIN7_YP
P1.38
XadcAIN6_YM
P1.39
XadcAIN0
P1.40
XadcAIN1
P1.41
WIFI0_PD_GPIO
P1.42
WIFI0_RESET_GPIO
P1.43
Xmmc2CLK/SPI_CLK2
P1.44
Xmmc2CMD/SPI_CSn2
P1.45
Xmmc2CDn/SPI_MISO2
P1.46
XEINT11
P1.47
Xmmc2DATA0/SPI_MOSI2
P1.48
Xmmc2DATA1
P1.49
Xmmc2DATA2
P1.50
Xmmc2DATA3
P1.51
XdacOUT
P1.52
XpwmTOUT0
P1.53
XEINT16/KP_COL0
P1.54
XEINT17/KP_COL1
P1.55
XEINT18/KP_COL2
P1.56
XEINT19/KP_COL3
P1.57
XEINT24/KP_ROW0
P1.58
XEINT25/KP_ROW1
P1.59
XEINT26/KP_ROW2
P1.60
XEINT27/KP_ROW3
P2
Spec
P2
Spec
P2.1
OM1
P2.2
GND
P2.3
M_nRESET
P2.4
OVDD_RTC_AP
P2.5
XuCTSn1
P2.6
XuRTSn1
P2.7
XuTXD0
P2.8
XuRXD0
P2.9
XuTXD1
P2.10
XuRXD1
