On Board Hardware
Resource
 1 x I2C-EEPROM (256byte) for I2C bus test
 4 x LEDs (green)
 4 x User’s Button (interrupt pin)
 1 x adjustor resistor for ADC test
 1 x PWM buzzer
 1 x backup battery for on board real time clock
External Resource
 4 x TTL
 1 x JTAG
 1 x LCD interface
 1 x SDIO
 2 x CMOS camera interface
 1 x matrix keyboard interface: 20pin
 1 x GPIO
PCB Dimension
 Four layered baord
 Dimension: 110 x 110 x 1.6(mm)
Bootload + OS
 Superboot
 Android 4.0
 Android 2.3 + Linux-2.6.35(kernel)
 Linux-3.0.8 + Qt4.8.5/Qtopia2/Qtopia4
 WindowsCE 6.0
2.1.3 Mini210S Board Dimension
