1.6.1 Smart210 1305 Carrier Board Hardware Feature
LCD
LCD1 interface: 45Pin, 0.5mm spacing, compatible with Mini2440/Mini6410
LCD, supports one wire precise touching
LCD2 interface: 40Pin, 0.5mm spacing, compatible with Mini2440/Mini6410
LCD, supports one wire precise touching
LCD4 interface: 44Pin, 0.5mm spacing, compatible with Mini2440/Mini6410
LCD, supports one wire precise touching and capacitive touch
HDMI high definition interface (Type A)
LCDs supported from 3.5” to 12.1” up to maximum resolution of 1024x768
Network
1 x 10/100M Ethernet interface(RJ45) using DM9000AEP
Standard Configuration
2 x DB9 RS232 serial port
1 x miniUSB Slave-OTG 2.0 which can be extened via a 2.0mm socket
1 x 3.5mm stereotype audio output
1 x integrated microphone
4 x USB Host 2.0
1 x standard SD card socket
1 x 5V power input (DC-23B)
