On Board Hardware
Resource
1 x I2C-EEPROM (256byte) for I2C bus test
8 x Interrupt Style Push Button on module
1 x PWM buzzer
1 x backup battery for on board real time clock
1 x G-sensor chip
External Resource
4 x TTL socket
1 x GPIO
1 x CMOS camera interface
1 x MIPI
PCB Dimension
Two Layered Board
Dimension: 180 x 130(mm)
Software
Superboot
Android 4.0
Android 2.3
Linux-3.0.8 + Qt4.8.5/Qtopia2/Qtopia4
CE6
1.6.2 Smart210 1305 Carrier Board Layout
