Connector
 2 x 60 pin 2.0 mm pitch header
 1 x 30 pin 2.0 mm pitch header
On Board Hardware
Resource
 4 x LED (Green)
 1 x Power LED (Red)
Power
 4.7V to 5.6V (support sleep mode)
PCB Dimension
 Eight layered board
 Dimension: 64 x 50 x 11(mm)
1.1.2 Tiny210 CPU Board Pin Spec
