 LCD3 interface (on the reverse): 40Pin, 0.5mm spacing, compatible with
Mini2440/Mini6410 LCD, supports one wire precise touching
 LCD4 interface (reserved): 40Pin, 2mm spacing, compatible with
Mini2440/Mini6410 LCD, supports one wire precise touching
 miniHDMI high definition interface (Type C)
 LCDs supported from 3.5” to 12.1” up to maximum resolution of 1024x768
Network
 1 x 10/100M Ethernet interface(RJ45) using DM9000AEP
Standard Configuration
 1 x miniPCIe interface
 2 x DB9 RS232 serial port
 1 x miniUSB Slave-OTG 2.0 which can be extened via a 2.0mm socket
 1 x 3.5mm stereotype audio output
 1 x integrated microphone
 3 x USB Host 2.0
 1 x standard SD card socket
 1 x 5V power input (DC-23B)
On Board Hardware
Resource
 1 x I2C-EEPROM (256byte) for I2C bus test
 8 x Interrupt Style Push Button on module
 1 x test pot for ADC testing
 1 x PWM buzzer
 1 x backup battery for on board real time clock
 1 x G-sensor chip
External Resource
 4 x TTL
 6 x channels AD Input
 1 x SDIO
 1 x CMOS camera interface
 1 x AV IN for CCD camera
