3.3 Technical specifications
Ash discharge system
Description Unit Ash discharge system
T4 TX P4 Pellet
Power supply to geared motor 230 V/50 Hz
Power consumption of geared motor W 180
Speed of coreless screw rpm 29
Weight of ash transfer box kg 17 14 13
Weight of gravity shaft with motor kg 14
Weight of hoses with screw kg 24
Standard dustbin
Description Unit Value
Net weight kg 37
Net weight including components kg 40
Capacity l 240
Max. load according to EN 840 kg 96
Material - Hot-dip galvanised sheet metal
Thickness of back and cover mm 1.25
3
Technology
Technical specifications
12 Fröling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com
