A Ash transfer box incl. flange for T4 F Coreless screw
B Ash transfer box incl. flange for TX G Tension rings
C Cladding for P4 Pellet H 1 pipe bend, 1 straight pipe
D Ash transfer box incl. flange
for P4 Pellet
I Gravity shaft with geared motor and
flexible high-temperature hose
E Supporting post J 240 l standard dustbin with attachments
4.2 Transport
The product is delivered on pallet(s) in cardboard packaging.
NOTICE
Possibility of damage to components if handled incorrectly
❒
Follow the transport instructions on the packaging
❒ Transport components with care to avoid damage
❒ Protect components against damp
❒ Pay attention to the pallet's centre of gravity when lifting
4
Assembly
Materials supplied
14 Fröling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com
