❒ Attach the high-temperature hose and connection flange to the gravity shaft using
the hose clamp
T4/TX:
P4 Pellet:
❒ Push the screw with the hose and drive unit as far as it will go into the ash transfer
box flange and then fix it in place using a tension ring.
Assembly
4
Assembling the ash discharge system
Installation and Operating Instructions Ash discharge into a standard dustbin | M1590214_en 25
