Fronius IG Plus 5.0-1 User Manual

95
setting ‘0’ for the minimum
possible contrast
4. Press the ‘Enter’ key to accept
the setting
5. Press the ‘Esc’ key to exit menu
item ‘CONTRAST’ or to maintain
previous setting
Setting menu
Setting menu
item
‘CONTRAST’
1. Select menu item ‘CONTRAST’
2. Press the ‘Enter’ key
Setting ‘7’ for maximum possib-
le contrast is shown
3. Use the ‘Up’ and ‘Down’ keys to
select the desired level of cont-
rast
item
‘LIGHTMODE’
1. Select menu item ‘LIGHTMODE’
2. Press the ‘Enter’ key
The ‘AUTO’ setting is shown
AUTO ... The display illuminati-
on will stop 30 seconds after
the last time a key has been
pressed.

Fronius IG Plus 5.0-1 Specifications

General

Nominal AC Power	5000 W
AC Nominal Voltage	230 V
Frequency	50 / 60 Hz
Max Apparent AC Power	5000 VA
Max Output Current	21.7 A
THD	< 3 %
Inverter Design	Transformerless
AC Connection	Screw terminals
