Fronius IG Plus 5.0-1 User Manual

81
Display Icon Unit Optional Display value
mode
‘Now’ W - output power
V - grid voltage
A - output current
Hz - grid frequency
V - module voltage
A - module current
°F / °C x module temperature
- - GFDI status
W x output reading of building load
meter
° F / ° C x ambient temperature
W/m² x irradiance
HH:MM x time
‘Day’ kWh / MWh - energy supplied
currency - yield
kg / T - CO
2
reduction
W - maximum power output
V - maximum grid voltage
V - minimum grid voltage
V - maximum array voltage
kwh / MWh x energy as read by building load
meter
° F / ° C x maximum module temperature
° F / ° C x minimum module temperature
° F / ° C x maximum ambient temperature
° F / ° C x minimum ambient temperature
W/m² x maximum irradiance
HH:MM - operating hours of Fronius IG
Plus unit
x optional
When the DatCom component for the required option is not available,
the message ‘N.A.’ (not available) is shown.
Overview of
Display Values
‘Year’
‘Total’

Fronius IG Plus 5.0-1 Specifications

General

Nominal AC Power	5000 W
AC Nominal Voltage	230 V
Frequency	50 / 60 Hz
Max Apparent AC Power	5000 VA
Max Output Current	21.7 A
THD	< 3 %
Inverter Design	Transformerless
AC Connection	Screw terminals
