Fronius IG Plus 5.0-1 User Manual

106
Setting menu
item ‘TIME’
(continued)
The fourth digit for the year
flashes
17. Use the ‘Up’ and ‘Down’ keys to
select a value for the fourth
year digit
18. Press the ‘Enter’ key
The set date then flashes:
19. Press the ‘Enter’ key
The first digit for the minutes
flashes
24. Use the ‘Up’ and ‘Down’ keys to
select a value for the first minu-
tes digit
25. Press the ‘Enter’ key
The time is shown (HH:MM, 0 -
24 h), the first digit for the hour
flashes
20. Use the ‘Up’ and ‘Down’ keys to
select a value for the first hour
digit
21. Press the ‘Enter’ key
The second digit for the hour
flashes
22. Use the ‘Up’ and ‘Down’ keys to
select a value for the second
hour digit
23. Press the ‘Enter’ key

Fronius IG Plus 5.0-1 Specifications

General

Nominal AC Power	5000 W
AC Nominal Voltage	230 V
Frequency	50 / 60 Hz
Max Apparent AC Power	5000 VA
Max Output Current	21.7 A
THD	< 3 %
Inverter Design	Transformerless
AC Connection	Screw terminals
