Fronius IG Plus 5.0-1 User Manual

150
Fronius IG
Plus 7.5-1
(continued)
Frequency trip limit accuracy 0.05 Hz
Frequency clearing times 0.016 - 300 s
Total harmonic distortion < 3 %
Power factor 1
* assured by electrical design of the inverter.
General data
Maximum efficiency 96.2 %
CEC efficiency at 208 V 95.0 %
at 240 V 95.5 %
at 277 V 96.0 %
Consumption in standby (night) < 1 W
Consumption during operation 15 W
Cooling controlled forced ventilation
Protection type NEMA 3R
Unit dimensions (w x h x d) 36.46 x 17.09 x 9.61 in.
926 x 434 x 244 mm
Inverter weight 57 lbs.
26 kg
Wiring compartment weight 26 lbs.
12 kg
Shipping dimensions (w x h x d) 42.72 x 20.28 x 14.02 in.
1085 x 515 x 356 mm
Shipping weight 90 lbs.
41 kg
Admissible ambient temperature -4 °F - +122 °F
(with 95% rel. humidity) -20 °C - +50 °C
Admissible storage temperature -4 °F - +140 °F
(with 95% rel. humidity) -20 °C - +60 °C
Protection devices
Ground fault protection internal GFDI (Ground Fault Detector/Interruptor)
Islanding protection internal
DC reverse polarity protection internal diode
Over temperature output power derating / active cooling

Fronius IG Plus 5.0-1 Specifications

General

Nominal AC Power	5000 W
AC Nominal Voltage	230 V
Frequency	50 / 60 Hz
Max Apparent AC Power	5000 VA
Max Output Current	21.7 A
THD	< 3 %
Inverter Design	Transformerless
AC Connection	Screw terminals
