58
CAUTION! Danger of damaging the inverter by overload.
Bevore starting up the inverter make sure, that a conductive
slug is inserted in each fuse holder for string fuses.
- Insert conductive slugs only with a fuse cover in the respec-
tive fuse holder
- Do not operate the Fronius IG Plus without fuse covers
7
2
1/2 in.
1
DC-
8
3
1
6x
2
3
4
DC-
1.33 ft. lb.
9
3
1/2 in.
2
1
DC+
10
2
3
6x
4
3
1
DC+
1.33 ft. lb.
NOTE
Form a min. 4 in. wire loop using all wires.
Solar Module
Ground at
Positive Pole:
Connecting
combined
Solar Module
Strings using
a DC String
Input Combi-
ner
(continued)
