Operating
Status LED
(continued)
Operating Status Explanation
LED
lights up red General status: the respective status code is
shown on the screen
remains dark There is no connection to the solar modules;
no power output from modules due to darkness
A list of most status codes, the corresponding status information, their
status causes and repair measures can be found in the chapter ‘Trouble-
shooting and Maintenance’, section ‘Status Diagnosis and Troubleshoo-
ting’.

Fronius IG Plus 5.0-1 Specifications

General

Nominal AC Power	5000 W
AC Nominal Voltage	230 V
Frequency	50 / 60 Hz
Max Apparent AC Power	5000 VA
Max Output Current	21.7 A
THD	< 3 %
Inverter Design	Transformerless
AC Connection	Screw terminals
