Attach the spatter tray retainer as shown
4
Screwing the
cleaning device
to the underlying
surface
WARNING!
Danger from machines falling or toppling over.
This can result in serious injury and damage to property.
▶
Always secure the cleaning device to the underlying surface.
▶
If the underlying surface thickness is less than 5 mm (0.197 in.), use the fixings sup-
plied with the cleaning device for fastening.
▶
If the underlying surface thickness is greater than 5 mm (0.197 in.), do not use the
fixings supplied for fastening. In this situation the installer is responsible for selecting
the right type of fixing.
1
Place the cleaning device and the spatter tray retainer on a level, firm and vibration-
free surface (foundation).
- Position the cleaning device in such a way that the distance the robot has to
travel to the cleaning position is as short as possible.
Place components on the underlying surface and secure
2
42
