Using the fill-level control sensor
General The fill-level control sensor emits a signal once the fill level in the parting agent container
falls below a specified level.
Controls and
indicators on the
sensor
(1)
(2)
(3)
(1) 'OUT OFF' button
for programming the sensor
(2) 'OUT ON' button
for programming the sensor
(3) LED
indicates the sensor operating
status
- LED on/flashing: sensor is act-
ive
- LED on/not flashing: sensor is
not active
Installation
adapter borehole
dimensions
57
15 3,2
4,2
28
36
13
24
3,2
mm
2.24
0.59 0.13
0.17
1.10
1.42
0.51
0.94
0.13
inch
