31
EN
(6) Lifting device
lifts the cleaning motor and the cleaning cutter when cleaning the inside of the gas
nozzle
(7) Cleaning motor with parting-agent injection nozzle
drives the cleaning cutter
(8) Compressed air connection for the wire cutter option
(9) Parting-agent injection nozzle
applies the parting agent to the inside and front of the gas nozzle
(10) Cleaning cutter
with internal through hole for the parting-agent injection nozzle
(11) "Spray parting agent" button
for manually testing the spray device - when the button is pressed, only the spray
device is activated (compressed air or a mixture of compressed air/parting agent is
sprayed from the parting-agent injection nozzle). The other functions of the clean-
ing device remain inactive.
(12) Gas nozzle clamping device
holds the gas nozzle in place during cleaning
(13) Protective covering
