Fronius Robacta Reamer V Easy - Robacta Reamer V Specifications

96
Robacta Reamer
V
Dimensions l x w x h 185 x 245 x 352 mm
7.28 x 9.65 x 13.86 in.
Weight
(without parting agent, wire cutter and mounting
plates for the wire cutter / Robacta Reamer V Easy
Han6P J)
11 kg
24.25 lb.
Supply voltage + 24 V DC
Nominal output 7.2 W
Nominal pressure 6 bar
86.99 psi
Air consumption 440 l/min
465 qt./min
Standard I/O (X1) Input: + 24 V DC/ max. 100 mA
Output: + 24 V DC / max. 30 mA
Cleaning time 3.0 - 5.0 s
Total cycle time 4.0 - 7.5 s
Parting agent container capacity 1 l
0.26 gal. (US)
Degree of protection IP 21
Marks of conformity CE, CSA
Safety symbols S
'Performance Level' c
Max. noise emission (LWA) 82 dB (A)
Dimensions l x w x h 185 x 250 x 350 mm
7.28 x 9.84 x 13.78 in.
Weight
(without parting agent and optional wire cutter)
11.5 kg
25.35 lb.
