Control elements and connections
Operating con-
trols and con-
nections
(3) (4)
(1)
(2)
(2)
(5)
(6)
No. Function
(1) USB port
The USB port allows a USB flash drive to be used to update the device
and also to log the charging parameters while charging is in progress.
(2) Position for options
- External start/stop option
- Temperature-controlled charging option
(3) Connection for (-) charging cable
(4) Connection for (+) charging cable
(5) Mains cable
(6) Position for electrolyte circulation option
