3
Use the "Up/Down" keys to select the desired parameter (e.g. "Cells").
4
Use the "Pause/Start" key to confirm the parameter.
5
Use the "Up/Down" keys to set the desired value (e.g. "24" for the number of
battery cells).
6
Use the "Pause/Start" key to confirm what you have entered.
If one or more relevant settings are changed for the charging process in configur-
ation mode, you will once again be prompted to confirm acceptance of the
changed settings when exiting configuration mode.
The following settings need to be confirmed when exiting configuration mode:
-
Characteristic
-
Battery capacity in Ah (excluding the RI characteristic)
-
Number of cells
-
Equalising charge ON/OFF
-
CAN protocol
Example:
Changing the characteristic from 3 -
UI (Pb-WET) to 6 - RI (Pb-WET).
If the setting is not confirmed, the
charger returns to configuration mode
and the setting can be changed to the
desired value.
Overview of
charging set-
tings
Below is a detailed explanation of the "Settings" menu item, selected under the
aforementioned "Charging settings" menu item. Navigation is carried out as de-
scribed in the Configuration mode section.
A list appears with the following selection options:
The individual selection options are explained in greater detail below.
38
