When you select a menu item you may
be presented with a prompt to read
the Operating Instructions. Confirm
this prompt by pressing the "Pause/
Start" key again.
The procedure for navigating the configuration menu and its submenus is as fol-
lows:
1
Use the "Up/Down" keys to select the desired menu item.
2
Use the "Pause/Start" key to confirm the menu item, and reconfirm any
double-check prompt (e.g. "OK?").
3
Use the "Up/Down" keys as necessary to choose an item, e.g. "Off/On" or
enter a value.
4
Use the "Pause/Start" key to confirm what you have entered.
5
If the cursor moves to another setting or position after confirmation of the
previous setting, repeat the procedure described in points (3) and (4).
To exit the current menu:
6
Press the "Menu" key to return to the higher-level menu.
See the following explanation of how
to set the charging settings by way of
example:
1
Use the "Up/Down" keys to select the "Charging settings" menu item.
2
Use the "Pause/Start" key to confirm this menu item.
The choice of settings for the "Charging settings" menu item will now be dis-
played:
the display may vary depending on the selection made. If the "Pb-WET" type of
battery has been selected in combination with the "RI" characteristic ("Curve") as
in the example here, the "Ah" heading is replaced by the "Charging time" setting
option.
Both the start and end time can be set for this charging time period. The starting
time can be deselected as required; the charging time then bases itself exclus-
ively on the specified charge end time following a manual charge start.
When applying the settings, the user will be guided through the menu in much
the same way as a wizard function.
37
EN
