Synergic Central control panel
General The functions on the control panel are all arranged in a logical way. The individual para-
meters required for welding can be
- selected easily using buttons
- altered using buttons or the adjusting dial
- displayed on the digital display during welding
The power source uses the Synergic control panel and certain general items of data
such as sheet thickness, filler metal, wire diameter and shielding gas to calculate the
best welding parameters. As a result, stored knowledge is available at all times. All the
parameters can be adjusted manually. The Synergic control panel also allows paramet-
ers to be set manually.
NOTE!
Due to software updates, you may find that your device has certain functions that
are not described in these operating instructions or vice versa.
Individual illustrations may also differ slightly from the actual controls on your device, but
these controls function in exactly the same way.
Safety
WARNING!
Danger due to incorrect operation and incorrectly performed work.
This can result in serious injury and damage to property.
▶
Read and understand this document.
▶
Read and understand all the Operating Instructions for the system components,
especially the safety rules.
