Connecting the mains cable
General A strain-relief device for the following cable cross-sections is fitted to the power source:
Power source Cable cross-section
Canada / US Europe
TSt 2700c AWG 14 to AWG 6 *) 4G2.5
TSt 3500c AWG 12 *) 4G2.5
*) Canada / US cable type: Extra-hard usage
Strain-relief devices for other cable cross-sections must be designed accordingly.
Stipulated mains
cables and strain-
relief devices
Power source Mains voltage Cable cross-section
Canada / US Europe
TSt 2700c 1 x 230 / 240 V AWG 14 (15 A) *) 3G2.5 (16 A)
TSt 2700c 1 x 240 V AWG 12 (20 A) *) -
TSt 2700c 1 x 240 V AWG 12 (30 A) *) -
TSt 2700c 3 x 200 V AWG 12 4G2.5
TSt 2700c 3 x 230 / 240 V AWG 14 4G2.5
TSt 2700c 3 x 380 / 400 V AWG 14 *) 4G2.5
3 x 460 V AWG 14 *) 4G2.5
TSt 3500c 3 x 380 / 400 V AWG 12 *) 4G2.5
3 x 460 V AWG 12 *) 4G2.5
*) Canada / US cable type: Extra-hard usage
The item numbers of the different cables can be found in the spare parts list.
American Wire Gauge
Safety
WARNING!
Danger due to work that has been carried out incorrectly.
This can result in serious injury and damage to property.
▶
The work described below must only be carried out by trained and qualified person-
nel.
▶
Observe national standards and directives.
CAUTION!
Danger due to improperly prepared mains cable.
This can cause short circuits and damage.
▶
Fit ferrules to all phase conductors and the ground conductor of the stripped mains
cable.
