Fronius TransSteel 2700c

Establishing a
ground (earth)
connection
1
Inserting/repla-
cing feed rollers
CAUTION!
Risk of injury if the feed roller holders fly upwards.
▶
When unlocking the lever, keep fingers away from the area to the left and right of the
lever.
In order to achieve optimum wire electrode feed, the feed rollers must be suitable for the
diameter and alloy of the wire being welded.
An overview of the available feed rollers can be found in the spare parts lists.
2
1
4
4
5
6
3
1
6
3
31
2
4
5
7
2
54
