1
Select the required setup parameter using the "Mode" and "Pro-
cess" buttons or the left-hand adjusting dial
Available parameters
Example: 1.00 | 4.21
Firmware version
Example: 2 | 491
Welding program configuration
Example: r 2 | 290
Number of the currently selected welding program
Example: iFd | 0.0
Motor current for wire drive in A
The value changes as soon as the motor is running.
Example: 654 | 32.1 = 65,432.1 hours = 65,432 hours 6 mins
Indicates the actual arc time since using for the first time
Note: The arc time indicator is not suitable as a basis for calculating hiring fees, for war-
ranty purposes, etc.
2nd
2nd menu level for service engineers
Keylock A keylock can be selected to prevent the settings from being inadvertently changed on
the control panel. As long as the keylock is active
- no settings can be made on the control panel
- only parameter settings can be retrieved
- any assigned "Save" button can be retrieved provided that an assigned "Save" but-
ton was selected when the keylock was enabled
Activate/deactivate the keylock as follows:
1
Press and hold the "Mode" button
2
Press the "Parameter selection" button (right)
3
Release the "Mode" and "Parameter Selection" buttons
Keylock activated:
The message "CLO | SEd" appears on the displays.
Keylock deactivated:
The message "OP | En" appears on the displays.
33
EN
