MIG/MAG standard manual welding
General The MIG/MAG standard manual welding process is a MIG/MAG welding process with no
synergic function.
Changing one parameter does not result in any automatic adjustments to the other para-
meters. All of the variable parameters must therefore be adjusted individually, as dictated
by the welding process in question.
Available para-
meters
The following parameters are available in MIG/MAG manual welding:
Wire feed speed
1 m/min (39.37 ipm.) - maximum wire feed speed, e.g. 25 m/min (984.25
ipm.)
Welding voltage
TSt 2700c: 14.4 - 34.9 V
TSt 3500c: 14.5 - 38.5 V
Dynamic
for influencing the short-circuiting dynamic at the moment of droplet transfer
Welding current
only for displaying the actual value
MIG/MAG stand-
ard manual weld-
ing
1
Press the "Process" button to select the desired welding process:
- MIG/MAG standard manual welding
2
Press the "Mode" button to select the desired MIG/MAG mode:
- 2-step mode
- 4-step mode
- In MIG/MAG standard manual welding, special 4-step mode corresponds to
conventional 4-step mode.
IMPORTANT! Under certain circumstances, it may not be possible to change
welding parameters that have been set on the control panel of a system
component (TR 2000 or TR 3000 remote control) on the control panel of the
wirefeeder.
3
Press the "Parameter selection" button to select the wire speed parameter
4
Use the adjusting dial to set the desired value for the wire speed
5
Press the "Parameter selection" button to select the welding voltage parameter
6
Use the adjusting dial to set the desired value for the welding voltage
The welding parameter values are shown in the digital display located above
them.
72
