Fronius TransSteel 2700c

Front and rear
sides, TSt 3500c
(1) (8) (7)
(2) (3) (4) (5) (6)
TSt 3500c
(1) Welding torch connection
for connecting the welding torch
(2) (-) - Current socket with bayonet latch
used for
- connecting the grounding (earthing) cable during MIG/MAG welding
- connecting the electrode cable or grounding (earthing) cable during MMA
welding (depending on the type of electrode used)
(3) (+) - Current socket with bayonet latch
used for
- connecting the electrode cable or grounding (earthing) cable during MMA
welding (depending on the type of electrode used)
(4) LocalNet connection
Standardised connection for remote control
(5) Mains switch
for switching the power source on and off
(6) Mains cable with strain relief device
(7) Air filter
(8) Shielding gas connection
