Cleaning the Device

399

Pinch the latch and then lower the top of the waste toner container and lift it away from

the main unit.

Note



To avoid toner spills or malfunction, keep the openings of the waste toner container facing up.



Do not touch the part indicated in the figure below after pulling out the waste toner container.

Lay the removed waste toner container with the openings facing up, on a flat place.

Remove the cleaning bar attached to the left side of the drum cartridges.
